◎Application Description

This product can be directly installed on oxygen cylinder and its output flow can be adjusted freely. Cylinder, nasal oxygen cannula and the product together make up a oxygen-supplier device, which is an ideal portable device to emergency supply oxygen for anoxic, breathless and dyspneic patients. It is a medical device necessary for public places such as medical units, long-distance bus stations, assembly room, theatre and so on.

The product can also be applied in environment pollution, special working, scientific research unit and emergent usage of small-scale welding and cutting.

◎Main Technology Data

  YQA series ammonia pressure reducer(Unit:mm)

Product type YQA-401 YQA-441
Applicable media Ammonia(NH3) Ammonia(NH3)
Input pressure 3MPa 3MPa
Adjusting range 0.01-0.06MPa 0.01-0.4MPa
Nominal flow rate 0.4m3/h 0.5m3/h
Specification (0-0.16,0-6)MPa (0-0.6,0-6)MPa
Weight 1.3kg 1.3kg
Outline size 70×155×125 70×155×125
Input port thread G1/2" G1/2"
Output port thread M16×1.5 M16×1.5
  • Product pictures
