SS Precision pressure gauge

SS Precision pressure gauge

If you have any questions, please contact us!
Contact Us

◎Application description

Stainless steel precision pressure gauge is widely used in oil industry, chemical industry , chemical fiber industry, metallurgical industry, power station and so on. It can precisely measure the pressure of medium which has high requirement of corrosion-proof.

And the gauge can also be used in checking general pressure gauge and precisely measure all kinds of medium, which is a good instrument for high precision measurement, science laboratory and industrial production process.

◎Main technology data

Type

YB-150BF

Measuring range
(MPa)

 -0.1~0;0~0.1; 0~0.16; 0~0.25; 0~0.4; 0~0.6;
0~1.0; 0~1.6; 0~2.5; 0~4; 0~6; 0~10; 0~16; 0~25; 0~40; 0~60;

Pressure unit

MPa psi bar kg/cm2etc.

Accuracy class

0.6% 0.4% 0.25%

Case

stainless steel

Connector

stainless steel

Movement

stainless steel

Anti-exploding slice

rubber

Pointer

65Mo manganese,black

Mounting type

bottom,back
bottom with flange , back with flange

Thread

M20*1.5 G1/2 NPT1/ ect.

  • Product pictures
